Useful Powershell Commands for Exchange

One of my recent projects was to implement a new Highly Available Exchange 2016 environment for a customer who was upgrading from Exchange 2010. When Exchange 2016 was in place, we then had to create  hybrid to Office 365. Below are some really useful PowerShell Commands I used during the implementation.

Installing Exchange 2016 Pre Requisites

Install-WindowsFeature AS-HTTP-Activation, Server-Media-Foundation,
NET-Framework-45-Features, RPC-over-HTTP-proxy, RSAT-Clustering,
RSAT-Clustering-CmdInterface, RSAT-Clustering-Mgmt,
RSAT-Clustering-PowerShell, Web-Mgmt-Console, WAS-Process-Model,
Web-Asp-Net45, Web-Basic-Auth, Web-Client-Auth, Web-Digest-Auth,
Web-Dir-Browsing, Web-Dyn-Compression, Web-Http-Errors, Web-Http-Logging,
Web-Http-Redirect, Web-Http-Tracing, Web-ISAPI-Ext, Web-ISAPI-Filter,
Web-Lgcy-Mgmt-Console, Web-Metabase, Web-Mgmt-Console, Web-Mgmt-Service,
Web-Net-Ext45, Web-Request-Monitor, Web-Server, Web-Stat-Compression,
Web-Static-Content, Web-Windows-Auth, Web-WMI, Windows-Identity-Foundation,
RSAT-ADDS

Collecting Virtual Directory Details

Outlook Anywhere

Get-OutlookAnywhere -AdPropertiesonly | Select server,Internalhostname,
Externalhostname

Outlook Web Access

Get-OWAVirtualDirectory -AdPropertiesOnly | Select Server,InternalURL,
ExternalURL

Exchange Control Panel

Get-ECPVirtualDirectory -AdPropertiesOnly | Select Server,InternalURL,
ExternalURL

Outlook Address Book

Get-OABVirtualDirectory -AdPropertiesOnly | Select Server,InternalURL,
ExternalURL

Web Services

Get-WebServicesVirtualDirectory -AdPropertiesOnly | Select Server,
InternalURL,ExternalURL

MAPI

Get-MAPIVirtualDirectory -AdPropertiesOnly | Select Server,InternalURL,
ExternalURL

Active Sync

Get-ActiveSyncVirtualDirectory -AdPropertiesOnly | Select Server,
InternalURL,ExternalURL



AutoDiscover

Collecting the AutoDiscover URI for Exchange 2010 Servers in the environment

Get-ClientAccessServer -identity SERVERNAME|select Name,
AutodiscoverServiceInternalURI |FL

Setting the AutoDiscover URI on the newly installed Exchange 2016 Server

Set-ClientAccessService -identity SERVERNAME -AutodiscoverServiceInternalURI
https://mail.domainname.com/autodiscover/autodiscover.xml



Exchange 2016 CU7 Hybrid Gotcha!!!

So after a successful deployment of Exchange 2016 the next step was to create a hybrid to Office 365 Exchange Online, Simple as Exchange 2016 was “Born in the cloud” according to Microsoft. NOT SO!!! – I downloaded the latest version of Exchange 2016 which at the time was CU7, but when configuring the hybrid it would just sit at adding Federated Domain.

A bug slipped into Exchange 2016 CU7 which prevents the HCW from completing. The HCW fails to get past the domain ownership validation:


No matter how hard you try, you can’t get past this screen.

Fortunately CU8 was release 19th December 2017 – So I spent the next day patching my newly installed Exchange environment. – then completing the Hybrid configuration.

Advertisements

Exchange 2010–Office 365 Hybrid Setup – Remote Powershell

Recently I have been getting issues with performing a hybrid configuration from an on premise Exchange 2010 Server running the latest services packs and meeting all the required pre requisites to perform a Hybrid configuration to Office 365.

One of the first steps is to connect your on Premise exchange server to Office 365 using remote PowerShell, following the how to guide it tells you to connect to the following URI in the command below:

$session = new-pssession -configurationname microsoft.exchange -connectionuri https//ps.outlook.com/powershell/ -credential $o365cred -authentication basic

When you run this command you will get the following error:

ps.outlook.com] The WinRM service cannot process the request because the request needs to be sent to a different machine. Use the redirect information to send the request to a new machine. Redirect location reported: https://ps.outlook.com/PowerShell-LiveID?PSVersion=2.0 . To automatically connect to the redirected URI, verify “MaximumConnectionRedirectionCount” property of session preference variable “PSSessionOption” and use “AllowRedirection” parameter on the cmdlet.+ CategoryInfo : OpenError: (System.Manageme….RemoteRunspace:RemoteRunspace) [], PSRemotingTransportRed
irectException + FullyQualifiedErrorId : PSSessionOpenFailed

After speaking with Microsoft I have identified the URI has changed to https://outlook.office365.com/powershell-liveid/

and the Powershell command is slightly different to include the –AllowRedirection as there are multiple servers to connect to.

The command that worked for me was the following:

$Session = New-PSSession -ConfigurationName Microsoft.Exchange -ConnectionUri https://outlook.office365.com/powershell-liveid/ -Credential $UserCredential -Authentication Basic -AllowRedirection

Connect to Exchange Online using remote PowerShell

What do you need to know before you begin?

  • You can use the following versions of Windows:
    • Windows 8 or Windows 8.1
    • Windows Server 2012 or Windows Server 2012 R2
    • Windows 7 Service Pack 1 (SP1)*
    • Windows Server 2008 R2 SP1*

* You need to install the Microsoft .NET Framework 4.5 or 4.5.1 and then either the Windows Management Framework 3.0 or the Windows Management Framework 4.0. For more information, see Installing the .NET Framework 4.5, 4.5.1 and Windows Management Framework 3.0 or Windows Management Framework 4.0.

Connect to Exchange Online

  1. On your local computer, open Windows PowerShell and run the following command.
    $UserCredential = Get-Credential

    In the Windows PowerShell Credential Request dialog box, type your Exchange Online user name and password, and then click OK.

  2. Run the following command.

    $Session = New-PSSession -ConfigurationName Microsoft.Exchange -ConnectionUri https://outlook.office365.com/powershell-liveid/ -Credential $UserCredential -Authentication Basic -AllowRedirection

    Note   If you are an Office 365 operated by 21Vianet customer in China, use the following value for the ConnectionUri parameter: https://partner.outlook.cn/PowerShell.

  3. Run the following command.

    Import-PSSession $Session

NoteNote:

Be sure to disconnect the remote PowerShell session when you’re finished. If you close the Windows PowerShell window without disconnecting the session, you could use up all the remote PowerShell sessions available to you, and you’ll need to wait for the sessions to expire. To disconnect the remote PowerShell session, run the following command.

Remove-PSSession $Session

How do you know this worked?

After Step 3, the Exchange Online cmdlets are imported into your local Windows PowerShell session as tracked by a progress bar. If you don’t receive any errors, you connected successfully. A quick test is to run an Exchange Online cmdlet—for example, Get-Mailbox—and see the results.

If you receive errors, check the following requirements:

  • A common problem is an incorrect password. Run the three steps again and pay close attention to the user name and password you enter in Step 1.
  • To help prevent denial-of-service (DoS) attacks, you’re limited to three open remote PowerShell connections to your Exchange Online organization.
  • Windows PowerShell needs to be configured to run scripts. You only need to configure this setting once on your computer, not every time you connect. To enable Windows PowerShell to run signed scripts, run the following command in an elevated Windows PowerShell window (a Windows PowerShell window you opened by selecting Run as administrator).

    Set-ExecutionPolicy RemoteSigned
  • The account you use to connect to Exchange Online must be enabled for remote Shell. For more information, see Manage remote PowerShell access in Exchange Online.
  • TCP port 80 traffic needs to be open between your local computer and Exchange Online. It’s probably open, but it’s something to consider if your organization has a restrictive Internet access policy.
